Enhanced Proprietary Chrome Process Produces A Thin, Dense, Uniform Coating That Features Superior Adherence And No Edge Buildup - offers superior properties when compared to common industry processes such as flash chrome, thin hard dense chrome (THDC).
Eliminates galling, seizing and high friction over a broad range of applications
Recommended as a finishing process eliminating costly secondary operations such as grinding
Processing does not adversely affect base material properties
Compatible with most ferrous and non-ferrous metals
Quality is consistent for any given base metal
Temperature range from 204C (399F) to 926°C (1699°F)
Allows flexibility of design and metal choice
Reduces wear and friction on sliding surface contacts
Provides enhanced erosion and corrosion resistance
Eliminates the need for undersize design calculation
Excellent abrasion resistance
No micro cracks to affect performance
Meets requirements of BAC 5709 CL4
Insures design reproducibility
Hardness in excess of 67 Rc
Practical and economical for any size order from individual components to high volume production quantities
Uniform in thickness and range from 0.0001-0.0003"
Resists attack by most organic and inorganic compounds with the exception of sulfuric and hydrochloric acids
A superior alternative to flash chrome, thin dense chrome (TDC) processes.
DYNALOY
Thin, dense, uniform chrome coating with no edge buildup. Offers reduced wear and friction on sliding surfaces. Excellent abrasion resistance. No micro cracks to affect performance.
Dynaloy
Wear
Corrosion
Lubricity
Anti-Stick
Temperature
FDA/USDA
NO
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
1 1.5 2 2.5 3 3.5 4 4.5 5
The DYNALOY enhanced proprietary chrome process protects base metals against wear, galling, friction, and corrosion. This specially developed surface enhancement creates a micro-surface that aids in lubricant dispersion. It eliminates friction over a wide range of applications and environments.
Because it is an extremely thin coating, it permits design engineers to specify a friction-resistant surface enhancement without affecting the tolerances in their designs. The coating provides for even further design possibilities because it was developed to adhere to any base metal. DYNALOY has rewritten the specifications of leading machine tool builders by establishing new standards for increased life and extended serviceability of machine guides. DYNALOY coatings reproduce, with precise detail, the surface morphology of the original metallic substrate. Parts after processing exhibit an attractive silver matte finish.
DYNALOY may be applied to all ferrous and non-ferrous metals with the exception of magnesium. Bath processing temperatures are maintained at 54.5°C (130°F) to 57.8°C (136°F). This ensures the base material's tensile, yield and fatigue properties are not adversely affected during processing. Thermal distortion is also minimized at these low temperatures.
Parts can be processed at any stage of their service life without the need for expensive machining operations to follow. Eliminating this requirement for post processing greatly reduces turnaround time and saves money.
