Protect Most Metals - Including Aluminum - Against Wear, Friction, Corrosion, Sticking and Galling. Provides superior properties when compared to other common industry coatings such as nickel plated, electroless nickel plated, sulfamate nickel, co-dep electroless nickel (or EN), polymer impregnated (or infused) electroless nickel.
  • NASA material #20386*
  • Dramatically increase surface hardness - up to Rc 68 (940 Vickers scale)
  • Resist corrosion, chemicals and acids
  • Prevent abrasive wear and galling and seizing
  • Self-lubricating for extended wear
  • Superior mold release
  • Meets and exceeds requirements for ASTM B656 and ASTM B733
  • Permanently dry-lubricated for very low COF
  • Many meet USDA/FDA and CFIA codes
  • Speed cleanup and sanitation maintenance
  • Eliminate sticking and product "hang-up"
  • Temperature range from -250°F (-157°C) up to 550°F (288°C)
  • Prevent galvanic corrosion with incompatible metals
  • Won't chip, peel or flake off like "paint-ons"
  • Non-porous surface eliminates the potential growth of mold and bacteria
  • Thickness - surface buildup is 0.0002" - 0.002" (±10%)
  • Non-wetting
  • Dielectric resistance, a low dissipation factor and very high resistivity over a wide range of frequencies
  • A superior alternative to other common industry coatings such as nickel plating, electroless nickel, sulfamate nickel, co-dep electroless nickel (or EN), polymer impregnated (or infused) electroless nickel
NEDOX SF-2 Hardness (up to Rc 65) combined with lubricity. USDA/FDA/CFIA-compliant. NASA material #20386.
NEDOX SF-2R Same as SF-2, but with superior mold release. USDA/FDA/CFIA-compliant
NEDOX MR3 (U4) Excellent mold release for plastics, urethane epoxies and rubber. Black color. Recommended for UV curing.
NEDOX SLK SLK is designed to provide the properties of SF-2 with improved anti-stick properties
NEDOX CR+ Maximum wear resistance. Hardness up to an equivalent of Rc 68. Maximum salt spray resistance.
NEDOX CR CR is designed to provide adequate wear protection and improved corrosion properties over CR+ with a higher COF
NEDOX 615 Maximum release properties. Operating temperatures up to 550°F (288°C). Sparkling black or white color. USDA/FDA/CFIA-compliant
NEDOX NH1 Excellent for resistance to wear and corrosion. Hardness of coating can be varied based upon specific requirements
NEDOX NH2 Hardness of coating can be varied for excellent corrosion and chemical resistance.
NEDOX FM-5 Special combination of proprietary polymers and dry-lubricants. Low coefficient of friction after burnishing.
NEDOX 641 Excellent release for food and drug molding and manufacturing applications. Grey in color, USDA/FDA/CFIA-compliant.
NEDOX 604 Maximum chemical resistance, mold release, and abrasion resistance. High dielectric strength. USDA/FDA/CFIA-compliant.
NEDOX NH-1SB Same as NH-1, with superior corrosion resistance to chlorinated solvents.
NEDOX SF-2SB Resists bleach washdown solutions and lactic acid from dairy equipment. USDA/FDA/CFIA-compliant
NEDOX HTR Excellent release at temperatures up to 1,400°F (760°C).
 Nedox SF-2
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
4 stars 2 stars 4 stars 3 stars 4 stars YES
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox SF-2R
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
3.5 stars 2 stars 4.5 stars 4 stars 4 stars YES
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox MR3 (U4)
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
2 stars 4 stars 3 stars 4.5 stars 4 stars YES
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox SLK
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
4 stars 2 stars 4.5 stars 4.5 stars 4 stars YES
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox CR+
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
4 stars 3.5 stars 4 stars 3 stars 4 stars YES
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox CR
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
3 stars 4 stars 2 stars 1 star 4 stars NO
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox 615
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
2 stars 4.5 stars 4 stars 5 stars 4 stars YES
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox NH1
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
3 stars 3 stars 2 stars 1.5 star 3 stars NO
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox NH2
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
3 stars 4 stars 2 stars 1.5 star 3 stars NO
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox FM-5
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
3 stars 2 stars 4.5 stars 2 stars 4 stars NO
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox 641
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
2.5 stars 4.5 stars 4 stars 4.5 stars 4 stars YES
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox 604
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
3 stars 4.5 stars 4.5 stars 4.5 stars 4 stars YES
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox NH-1SB
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
3 stars 4.5 stars 2 stars 1 star 3 stars NO
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox SF-2SB
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
4 stars 4.5 stars 4 stars 3 stars 4 stars YES
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
 Nedox HTR
Wear Corrosion Lubricity Anti-Stick Temperature FDA/USDA
4 stars 2 stars 4.5 stars 3.5 stars 5 stars NO
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.
1 star1
1.5 star1.5
2 stars2
2.5 stars2.5
3 stars3
3.5 stars3.5
4 stars4
4.5 stars4.5
5 stars5

NEDOX improves parts made of less durable and/or less costly metals by adding physical properties that permit them to outperform and outwear even chrome and stainless steel.

* MSFC Handbook 527F (NEDOX SF-2), Johnson Space Flight Center #D9604F

NEDOX is well suited for use in reactors that are used for uranium enrichment. In the process that creates fissionable Uranium 235 from Uranium 238, uranium hexafluoride (UF6) is produced in a gaseous diffusion process. The UF6 was found to be one of the most active chemicals known, almost acting as a universal solvent. The components in Nedox are shown to have excellent chemical resistance to UF6.

Typical Coefficient of Thermal Expansion: 7.22 x 10-6 in/in/1°F. (13 x 10-6 in/in/1°C). Typical Coefficient of Thermal Conductivity: .0105 - .0135 Cal-cm/sec/°C.

A 0.001" coating shows little or no corrosion after 14 months of continuous exposure to atmosphere and salt water. Good resistance to most common chemicals. Certain coatings show no effect after 90 days immersion in pH 3.0 - 9.5 solutions. Some NEDOX coatings are especially resistant to phosphate-free bleach used in washdown solutions in food processing and packaging operations. NEDOX coatings on aluminum also provide resistance to a wide range of chemicals.

A few typical applications

  • Aircraft
  • Aerospace
  • chemical processing equipment
  • electronic equipment
  • food processing
  • heat sinks
  • meters (gas & electric)
  • molds (release media)
  • packaging equipment
  • pharmaceutical processing
  • pumps
  • sealing equipment
  • textile manufacturing
  • valves
