Superior chemical and corrosion resistance
Lectrofluor® is a polymer-based coating that prevents severe corrosion and chemical attack to metals in hostile environments. The coating features proprietary blends of engineered polymers and a low coefficient of friction.
Metal parts are first cleaned and prepared in specially designed equipment. The selected polymers are then applied by standard spray methods or electrostatic spraying, depending on the polymers and the part's end use.
Choosing the right polymers
Compatibility with all ferrous and non-ferrous metals other than magnesium.The decision of which polymer to use is based on several factors including:
- The end-use application of the part
- Its base metal
- Hostility of the environment
- Coating buildup; tolerance requirements
Technical advantages
Lectrofluor provides superior properties compared to other common industry coatings such as fluoropolymers, TFE, PTFE, PFA and FEP. Lectrofluor properties include:
- Dry lubricity for low coefficient of friction
- USDA and FDA compliance
- Prevention from abrasive wear and galling
- Heat stability
- Permanent self-lubricating properties for extended wear
- Mold release properties
- Operating temperature range: -400°F (-204°C) to 600°F (315°C)
- Corrosion, radiation and UV resistance
- Thickness range 0.001 to 0.030 inches
Type | Description | Wear | Corrosion | Lubricity | Anti-Stick | Temperature | FDA and USDA |
615 | Superior pigmented USDA- and FDA-compliant polymer that offers superior mold release, is unaffected by UV weathering and has cryogenic stability to 550°F with a very low COF. | ![]() |
![]() |
![]() |
![]() |
![]() |
YES |
615L | Version of 615 additional durability. | ![]() |
![]() |
![]() |
![]() |
![]() |
YES |
641 | Excellent release for food and drug molding and manufacturing applications. Grey in color. Temperature range to 500°F. | ![]() |
![]() |
![]() |
![]() |
![]() |
YES |
601 | Excellent corrosion, chemical and abrasion resistance. High oxidative stability. Excellent mechanical toughness and cut-through resistance. Good electrical properties. | ![]() |
![]() |
![]() |
![]() |
![]() |
NO |
608 | Specifically designed for rubber molding applications where toughness and release are required. USDA and FDA compliant. Also good for cheese and food applications requiring durability and release. | ![]() |
![]() |
![]() |
![]() |
![]() |
YES |
611 | Superior corrosion and impact resistance. Permits fast, easy cleanup of equipment parts. Resists staining. Selected colors available. | ![]() |
![]() |
![]() |
![]() |
![]() |
NO |
605 | Developed to provide superior non-stick properties and withstand harsh cleaning agents. FDA/USDA Compliant. Download The Brochure → |
![]() |
![]() |
![]() |
![]() |
![]() |
YES |
609 | Excellent durability and release for food, drug and manufacturing applications. FDA compliant and temperature range up to 400F. | ![]() |
![]() |
![]() |
![]() |
![]() |
YES |
621 | Multi-polymer system that has excellent release (non-stick) properties along with low COF. Temperature range up to 525F. | ![]() |
![]() |
![]() |
![]() |
![]() |
YES |
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff. |
Ideal applications
- Chemical processing equipment
- Air moving equipment
- Pumps
- Scrubbers
- Pipe valves
- Meter housings
- Mixing vats
- Probes
- Mounts
- Housings
- Dryers
- Stirrers
- Sealing dies
- Conveyor lines
