Magnaplate HMF

Mirror-smooth coating eliminates static buildup

Magnaplate HMF® is a proprietary, multi-step coating process that produces a mirror-smooth surface with a microfinish as low as 4 Ra. The coating can obtain a hardness of up to 68 Rc and can be applied to ferrous metal, copper or aluminum alloys. The purpose of the coating is to create a microfinish that produces a low coefficient of friction. Magnaplate HMF can operate in a range from as low as -250°F (-157°C) to as high as 950°F (510°C).

Salt spray per ASTM B-117 exceeds 336 hours when thickness of coating is 0.001 inches or greater. Magnaplate HMF provides a level of chloride protection better than chrome plating.

Technical advantages

Magnaplate HMF provides superior properties when compared to other chrome and bright nickel coatings. Magnaplate HMF offers:

  • Applicable for most base metals
  • Prevention of scratching of films and foils
  • Excellent corrosion and moisture resistance
  • Temperature range from -250°F (-157°C) up to 950°F (510°C)
    • Suggested useful operating range is up to 650°F (343°C)
  • Electrically conductive
  • COF 0.05 against burnished Hi-T-Lube®
  • Good heat transfer
  • Resists peeling, chipping or cracking
  • Elimination of stick-slip
  • Compliance with FDA and USDA codes
  • Exceeds 336 hours of salt spray per ASTM B-117
  • Reflective chrome-like appearance
  • Elimination of stress lines in sensitive plastic film processing
  • Effective insurance against galling and seizing
  • Excellent bond to parent metal
  • Environmentally acceptable, preferred to chrome
  • Increased hardness up to 68 Rc
  • Chloride protection vastly superior to chrome plating
  • Permanent lubricity
  • Maximum abrasion resistance
  • Mold release
  • Will not mar printed surfaces
  • No polymer toxicity
Type Wear Corrosion Lubricity Anti-Stick Temperature USDA and FDA
Ratings are meant for reference only. For specific application recommendations contact the General Magnaplate technical staff.

Ideal applications

  • Pharmaceutical manufacturing
  • Calendering rolls
  • Cosmetic manufacturing
  • Embossing
  • Paper, film and foil production
  • Chutes
  • Plastic molding and extruding
  • Hoppers
  • Closure devices
  • Folders
  • Ball valves and seats
  • Packaging
  • Engine pistons and cams
  • Aerospace
  • Tobacco processing equipment
